Description

The EBS OctaBass was the first effect unit ever made by EBS. Known for its lightning-quick tracking and naturally fat tone, it offered a single octave drop and a set of simple controls. The Blue Label version adds new features and a streamlined interface — maximum sound, minimum fuss!

Key Features

• Preserve the low range
• Suitable for live and studio use
• High or low optimized fretboard tracking-range
• Controls for Normal and Octave volume
• Seamless Tone control for octave
• Can be powered with 9-18V DC

Improved Tracking

A range switch lets you change the pedal’s tracking focus from lower in your bass range to higher. This ensures ultra-precise tracking, unprecedented for an all-analogue pedal at this price-point.

Enhanced Tone Control

By adding a seamless tone control you can go from a present, focused octave sound that cuts through the mix all the way to a sub-bass backdrop of lows that discreetly supports the note you play. The tone control enhances the palette of sounds and also makes it easier to achieve a synthesized bass sound.

Specifications

• Nominal Input Level: -10 dBv
• Input Impedance: 1.8 Mohms
• Output Impedance: 100 ohms
• Dry Bandwidth +0/-2 dB: 20 – 20k Hz
• Dry Level min/max: -oo / 0 dB
• Octaver Level Gain min/max: -oo / 12 dB min
• Octaver Tone Filter: Low Pass, Slope >18 dB/octave, Range 60 – 350 Hz
• Triggering Threshold: -70 dBv @200 Hz
• Dimensions: W x H x D 2.6” x 4.5” x 1.9”
• (67 x 115 x 48 mm)
• Weight: 315g (0.7 lb.)
• Type: Analog Effect, Relay type Switching
• Power Requirements: 9, 12 or 18 V DC, 40 mA max. Pedal shuts off below 6.0 V
