Description
Here's What Disaster Area Say About the PBA-4 Dual Junction Box – Standard Edition
The PBA-4 Dual Junction Box is a passive jack module for your pedalboard.
Consisting of four high-quality isolated jacks, the PBA-4 can serve in a variety of signal routing applications.
Standard Version
The PBA-4 is small enough to mount underneath the angle of most Pedaltrain boards (including PT-Jr, PT-1 / 2 / 3, PT-Pro, PT Novo series, and PT Classic series) to allow for a convenient input or output point.
The standard version has each pair of jacks wired together in parallel.
Connect two pedalboard patch cables between your first and last pedals and the PBA-4, and then you can plug in your instrument cables directly to your board saving valuable setup time.
Use a single PBA-4 as both input and ouput points for your board, or use the PBA-4 as a stereo output junction. Both tip and ring connectors are wired through on the PBA-4, so it can also serve as a connection for expression pedals or stereo patch cables.
Specifications
- 3.6″ x 1.5″ x 1.2″ (92mm x 38mm x 31mm)
- Passive design, no power supply or batteries required
- High-quality Neutrik jacks
- Die-cast aluminum enclosure
- Standard version: Tip-ring-sleeve wired through on each junction channel
