Maxon OD-808X Overdrive Extreme Pedal

Maxon OD-808X Overdrive Extreme Pedal

£119.99

Guitars Pedals Amps & Stuff are excited this week as the almighty Maxon OD-808X Overdrive Extreme Pedal is now back in stock. These are built to an exceptionally high standard. We deliver Maxon Guitar FX straight to your door via our tracked *roadie service* across the UK, Europe, and the USA. A firm favourite among the finest gear available in the UK. if you want the full low down, click through to the Maxon crew direct for more details, images, specs, and all the good stuff. When even legendary overdrives just aren’t enough, it’s time to go to the extreme…

More Details

View more in
Tags: ,
View more by

Description

Guitars Pedals Amps & Stuff are excited this week as the almighty Maxon OD-808X Overdrive Extreme Pedal is now back in stock. These are built to an exceptionally high standard. We deliver Maxon Guitar FX straight to your door via our tracked *roadie service* across the UK, Europe, and the USA. A firm favourite among the finest gear available in the UK. if you want the full low down, click through to the Maxon crew direct for more details, images, specs, and all the good stuff.

When even legendary overdrives just aren’t enough, it’s time to go to the extreme – the OD808X Overdrive Extreme

For over 30 years Maxon’s legendary “808” overdrive circuit has been an essential ingredient to achieving great guitar tone. Whether it’s used as a booster to drive an amp, as a Dirt box for crunch and extra sustain or as an EQ to shape the tone of a high-gain amp, the 808 in its many incarnations has shown up in more rigs and on more recordings than anyone would care to count.

Yet for all its legendary status, there are some who wish the 808 offered just a little bit more – and for those players obsessed with excess, Maxon has created the OD808X Overdrive Extreme. The OD808X offers a wider frequency response than a stock OD808, with an extended hi-frequency tonal range that offers additional clarity without becoming harsh.

Specifications

  • Modified version of classic OD808 Overdrive
  • Extended frequency response improves note definition and clarity
  • Increased Output (+5 dB over OD808) for extra Volume Boost
  • Harder clipping yields more aggressive, amp-like Distortion
  • Buffered Bypass Switching
  • Input Impedance: 500K Ohms
  • Output Impedance: 10K Ohms
  • Maximum Gain: 40dB (2 kHz)
  • Input Noise: -110dB or less (Input shorted, IHF-A weighted)
  • Controls: DRIVE, TONE, LEVEL
  • Switch:
  • BYPASS/EFFECT (Buffered Electronic Bypass)
  • Indicator: BYPASS/EFFECT LED
  • Power Supply: 6F22/6LF22 9V battery x 1 or Maxon AC adaptor
  • Power Consumption: 7.2mA max. / 9VDC
  • Battery Life:
  • 9VDC manganese battery 78 hours 25 deg C (FUJITSU 6F22)
  • 9VDC alkaline battery 114 hours 25 deg C (TOSHIBA 6LF22)
  • Dimensions: 70(W) x 113(D) x 56(H) mm
  • Weight: Approx. 300g (incl. battery)
  • Accessory: 6F22 9V battery x 1, operating manual

Stuff About Maxon

Maxon are known for making standout effects pedals and more. Founded with a passion for tone and innovation, their gear has shaped countless records and players’ sounds. Look out for their iconic designs and flagship models — they’ve earned a reputation for reliability and creativity.

The Important stuff

Guitar FX — Guitar effects pedals add character, texture, and personality to your sound. From subtle ambience and reverb to heavy distortion or experimental modulation, effects shape how your guitar interacts with the world. A good setup starts with the basics like overdrive, delay, and chorus, then expands into creative territory with fuzz, phaser, or looper pedals. Whether you want vintage tones or modern soundscapes, experimenting with different combinations will help you discover your own signature style.. Overdrive — Overdrive pedals add warmth, grit, and natural compression to your tone, capturing the feel of a pushed tube amp. They respond dynamically to your playing, offering everything from a light bluesy crunch to full, saturated rock tones. Perfect for boosting solos or shaping your core sound, an overdrive pedal brings character and life to any setup. Whether you prefer vintage smoothness or modern bite, these pedals are essential for players who want expressive, touch-sensitive drive with plenty of personality..
